ua2018a digital clamp meter

UA2018A Digital Handheld Clamp Multimeter Tester DMM Voltmeter Amp AC DC Voltage and AC current tong tester

Digital clamp meter,UYIGAO 2000 Counts Auto Range multimeter with AC/DC Voltage, Resistance, AC Current, Diode Test, Build in Flashlight and LCD Display (UA2018A)

Specification:
--Display: 3 1/2 digital LCD display
--Clamp Flashlight , LCD Backlight, Date Hold and Low Battery Indication
--DC Voltage and Accuracy: 2~600V ±(0.8%+5)
--AC Voltage and Accuracy: 2.0~600V ±(1.2%+5)
--Resistance and Accuracy: 200Ω~200MΩ ±(1.2%+5)
--AC Currentand Accuracy: 2A~600A ±(2.5%+8)
--Max display value: 1999
--Diode Test: Yes
--ON-OFF Buzzer: Yes
--Low Battery Display: Yes
--Data Hold: Yes
--Auto Power off: Yes
--Function Protection: Yes
--Operating Mode: Manual Range
--Back Light Function: Yes
--Back Lighting: Yes
--Led Torch: Yes
--Size: 208x79x36mm
--Max Clamp Jaw Opening: φ36
--Power Supply: AAA 1.5V*3 Batteries
--NOTE: Batteries are not included!!!
--Weight: 333g
--CE Certified Clamp Meter


Package Content:

1xDigital Clamp Multimeter
1xUser's Manual
1xCarry Case
1xTest Leads





·Different Testing Range of this three Clamp Meter: UA2018A testing AC/DC Voltage Resistance AC Current Diode for your basic needs;UA2018B testing AC Current AC/DC Voltage Resistance Capacitance Temperature Frequency Inrush Current NCV Diode;UA2018D testing AC/DC Current, AC/DC Voltage, Resistance, Capacitance, Temperature, Frequency, Duty Ratio, Inrush Current, NCV, Diode.


·Different Display of this three Multimeter:UA2018A is 3 number 1/2 digital LCD display,max display value is 1999; UA2018B and UA2018D both are 3 Number 3/4 digital LCD display max display value is 5999.


·Multi choice for your Needs:UA2018A is for your basic needs,UA2018B is for a little professional needs, if you need a super professional clamp meter and want to test DC current please choose UA2018D,note UA2018A and UA2018B can’t test DC current;


·Convenient Flash Light and Portable Design: one-hand holding design allows you do testing by one hand, portable size come with a pack bag is convenient for you to take it anywhere, Build in LED flashlight for clamp measuring in the dark area;


·Maximum jaw opening size: 36mm. Comes with upgraded test leads LCD backlight, data hold and low battery indication, Comes with upgraded test leads,


·Over-range indication: LCD will display OL. Power: 3 x AAA 1.5V ( Batteries are not included here)


Please note UA2018A clamp only measure AC current,it don't support DC current.

NOTE: Batteries are not included!!!



Package Content:1 x Digital Clamp Meter

1 x Pouch Bag

1 x English Manual
